18

Specications (continued)

EXTERNAL DIAGRAM OF RANGE HOOD

18 mm

(0.69 in)

757 mm (29.8 in)

705 mm (27.75 in)

250 mm (9.81 in)

280 mm (11 in)

35 mm

(1.4 in)

(1.5 in)

38 mm

80 mm

(3.13 in)

28 mm

(1.1 in)

22 mm

(0.88 in) D

270.6 mm (10.65 in)

355 mm (14 in)

5 in

(127 mm )

458 mm (18 in)

193.5 mm

(7.62 in)

757 mm (29.8 in)

193.5 mm

(7.62 in)

TOP

BOTTOM

50 mm

(2 in)

250 mm

(9.81 in)

9 mm

(0.35 in)

21 mm

(0.8 in)

22 mm (0.88 in) D
